Brake Shoes

15" Drum Diameter Single Web

Arvin Meritor

T Style Brake
Shoe Width = 3-1/2" FMSI No. = 1307P
Shoe Width = 4" FMSI No. = 1308P
Hardware Kit No. = RF2ARK

---

Arvin Meritor

Q Style Brake
Shoe Width = 4" FMSI No. = 1308Q
Hardware Kit No. = RF3

---

Eaton

Single Anchor Pin Front Brake
Shoe Width = 4" FMSI No. = 1308E
Hardware Kit No. = EF1

---

Eaton

ES Single Anchor Pin Front Brake
Shoe Width = 4" FMSI No. = 1443E
Hardware Kit No. = EF1

---

Wagner

Front Axle Brakes
Shoe Width = 4" FMSI No. = 1308W2
Shoe Width = 4" FMSI No. = 1308W6
Shoe Width = 4" FMSI No. = 1308W8
Hardware Kit No. = WF1

---

Arvin Meritor

RSA Wedge Brake-Used On Steer Axles OBSOLETE
Shoe Width = 4" FMSI No. = 1308MW
Hardware Kit No. =

---

Arvin Meritor

Wedge Brake
Shoe Width = 3-1/2" FMSI No. = 4562MW
Shoe Width = 4" FMSI No. = 4610MW
Shoe Width = 5" FMSI No. = 4615MW
Shoe Width = 6" FMSI No. = 4605MW
Shoe Width = 7" FMSI No. = 4602MW
Hardware Kit No. =

---

Bendix

Wedge Brake OBSOLETE
Shoe Width = 5" FMSI No. = 4615BW
Shoe Width = 6" FMSI No. = 4605BW
Shoe Width = 7" FMSI No. = 4602BW
Hardware Kit No. =

---

Lucas Girling

Hydraulic Brake used on Ford trucks
Shoe Width = 5" FMSI No. = 4528LG
Shoe Width = 6" FMSI No. = 4504LG
Shoe Width = 7" FMSI No. = 4505LG
Hardware Kit No. =
